Factory Price 8*4 Shacman F3000 Concrete Mixer Truck with 14CBM Mixer Tanker Capacity for Sale
- Commodity name： Factory Price 8*4 Shacman F3000 Concrete Mixer Truck with 14CBM Mixer Tanker Capacity for Sale
- Condition： Brand New
- Tyre Quantity： 12 tyre
- Driving Type： 8×4
Keyword:
Product Description
Basic parameters
Model: SX5315GSNJU456, SX5258GJBJT384C
Maximum speed (km/h): 85, 70
Wheelbase (mm): 3775+1400
Engine: WP10.340E22+PTO Euro II, ISM11E5 385+PTO Euro V
Horsepower: 340hp, 380hp
INTRODUCTION
Introduced in 2009, Shacman F3000 series the one of the best seling product. Reliable, rugged and powerful, Shacman F3000 series can tackle any task its owner ask of it.
Shacman F3000 is the first choice for overseas engineering projects. This series platfortm also has the largest volume in the international market,winning the hearts of its operators.
Product features
Long lasting: Wuhan steel, Baoshan steel material, different thickness for different parts,wear rib on blades. Service life is 1.5 times than average.
Unique structure: Revised logarithmic spiral blades, Special mold cold press molding, to ensure speed of concrete in and out, ensure the uniformity of the concrete.
Well-equipped:CNC cutting equipment, Automation Welding System, fixtures, Automatic robot welding production line (on trial), to ensure quality.
Patent technology: blade curve, antitorque secondary beam, tank heating equipment etc;
High-level configuration: imported hydraulic system
from Germany, Italy, America.
Parameter
| Platform | Shacman F3000 | |
| Drive type | 8×4 | |
| Vehicle model | SX5315GSNJU456 | |
| Vehicle Weight | GVW：15 tons | |
| GCW：35 tons | ||
| Frame | 850×300(8+7) | |
| Engine | Weichai | Emissions: Euro II to Euro V |
| Displacement: 10L – 12L | ||
| Power: 300 PS – 420 PS | ||
| Torque: 1200 Nm – 2100 Nm | ||
| Cummins | Emissions: Euro II to Euro V | |
| Displacement: 10L – 12L | ||
| Power: 340 PS – 420 PS | ||
| Torque: 1200 Nm – 2100 Nm | ||
| Transmission | 12JSD200T-B+QH70 | |
| Clutch | φ430 | |
| Steering gear | ZF8098 | |
| Axle | Front axle: MAN 9.5 ton | |
| Rear axle: MAN 16 ton single or double reduction | ||
| Gear ratio: 4.769 – 5.92 | ||
| Suspension | Multi leaf spring front and rear setup | |
| Tires | 315 / 80R22.5 | |
| 12R22.5 | ||
| 12.00R20 | ||
| Fuel tank | 400 - 700 liter aluminum or steel tank | |
| Dimensions(LxWxH) | 10800×2490×3300 | |
| Volume(m³) | 12-18 | |
| Wheelbase | 1800+4575+1400mm | |
| Approach/Departure angle(°) | 20/12 | |
| Max.gradeability(%) | 27 | |
| Cab | Type | SHACMAN F3000, lengthened flat roof |
| Equipments | ◆Rear window ◆Manual sunroof ◆Hydraulic driver seat with seatbelts ◆Hydraulic suspension of cab ◆Electronic air conditioning with temperature control ◆Electric window ◆Radio with MP3 player |
|
| Optional | ●Air cushioned drivers seat ●Full vehicle WABCO valve |
|
