Shacman Crane Cargo Truck Shacman H3000 Construction Crane Truck 8x4 430hp
- Commodity name： Shacman Crane Cargo Truck Shacman H3000 Construction Crane Truck 8x4 430hp
- Condition： Brand New
- Tyre Quantity： 12 tyre
- Engine Power： 430HP
- Driving Type： 8×4
- Loading Capacity： 80 tons
Keyword:
Product Description
Shacman H3000 folding arm Crane is a multi-functional vehicle, with a lifting capacity of 30 tons, adopts folding arm design, with flying arm and climbing function, suitable for four or eight configurations. This crane is designed to provide the convenience of a multi-purpose vehicle to meet the needs of a variety of work scenarios.
Shacman H3000 Its onboard crane features automatic air conditioning, airbag seats, daytime running lights, dashcam and central lock and other high-end features designed to provide a comfortable driving environment. In terms of power, it is equipped with a powerful engine and gearbox, with high and low gear switching function to cope with various load requirements.
Shacman H3000 folding arm crane also uses 300mm three-layer straight girder and strong steel wire tire to ensure the stability and reliability of operation. These features make Shacman H3000 folding arm crane an efficient, multi-functional logistics and engineering equipment that can meet the needs of various working environments .
| Cargo Crane Truck Parameters | ||
| Model | SX5315JSQMT456 | |
| Drive type | 8x4 | |
| Weight | Gross Vehicle Weight | ≤50 |
| Dimensions | Wheelbase/(mm) | 2100+4575+1400 |
| Performance | Maximum speed/(km/h) | 60～75/115 |
| Ground clearance | >314 | |
| Engine | Brand | WEICHAI |
| Model | WP12.430E22 | |
| Power/(kw/HP) | 3160w / 430Hp | |
| Maximum torque / (N.M)/rpm | 1900 N·M | |
| Displacement/(L) | 11.596 L | |
| Emission standard | Euro/ II | |
| Gear box | Brand | FAST |
| Model | 10JSD180+QH50 | |
| Clutch | Type | φ430 Diaphragm spring clutch |
| Cooling | Type | Domestic heat sink |
| Air inlet | Type | Ordinary air filter |
| Brakes | Type | Drum brake |
| Service brake | Double circuit air brake | |
| Park brake | Rear wheel spring brake | |
| Auxiliary brake | WEVB engine exhaust brake | |
| Steering | Type | ZF8098 technology, circulating ball steering machine |
| Chassis | Type | Parallel trapezoidal frame with variable section |
| Dimensions/(mm) | 850×300(8+5+8) | |
| Suspension | Front | Front /rear multi-layer plate spring 4 main plates + 4 U-shaped bolts |
| Rear | Front /rear multi-layer plate spring 4 main plates + 4 U-shaped bolts | |
| Axles | Brand | HANDE |
| Front axle | MAN 9.5T | |
| Rear axle | 2*16 T Double-stage, speed ratio-5.262 | |
| Tires | Type | 12.00R20 |
| Fuel tank | Tank capacity/(L) | 300L |
| Electrics | Type | 24V |
| Battery | 165Ah Maintenance-free battery | |
| Cab | Type | SHACMAN H3000 medium-length flat roof |
| Equipment | Hydraulic main seat, electronically controlled automatic constant temperature air conditioner, electric window shaker, 165Ah maintenance-free battery, SHACMAN Logo, full English logo. | |
| Super structure parameters | ||
| Crane lifting type | Hydraulic | |
| Crane capacity | 5-16ton | |
| container size | 6800*2350*600mm(customized ) | |
| container material | High strength carbon steel | |
| Container thickness | 6mm Side,8mm bottom | |
